#14300387 Mast Assembly

发布日期：2026-03-24

#14300387 Mast Assembly
#Sany Rotary Drilling Rig  #Sany Rotary Drilling Rig parts
#sanyparts #sany  #SR405RH10 rotary drilling rig body
#Rotary Rig #sanyparts #sany # #SR405RH10
WhatsApp: 136 8539 5801
WhatsApp: 136 8539 5801
WeChat: 136 8539 5801
14300387 Mast Assembly
1 14295204 Pulley Assembly 1

2 14063029 Pin SR280RC8.4-5B 2

3 13008751 M30 Rubber Plug 7

4 13122049 Shaft End Plate 6

5 A210111000024 Bolt 4

6 21001328 Washer 15

7 10004098 Locking Pin 1

8 12613164 Connecting Seat 2 1

9 21001338 Washer 16GB97.1 300HV 30

10 A210111000053 Bolt 4

11 13656295 Pin 1

12 13138797 Protective Cover 1

13 24000633 Washer 8GB97.1 Dacrust 7

14 24000511 Washer 8GB93 Dacrust 7

15 A210111000323 Bolt 4

16 A290000002660 Grease Necklace Universal Protective Cap 24

17 A210804000002 Grease Necklace 11

18 11325573 Soil Cleaner Cylinder 1

19 A210412000133 Washer 22GB858 2

20 A210304000019 Nut M22×1.5GB812 2

21 13163083 Nylon Sheet 1

22 A210204000341 Screw 4

23 11087485 2 Pins

24 14285438 Upper Mast 1

25 13168941 Extended Mast Assembly 1

26 14207088 Middle Mast 1

27 14394210 Guide Pulley Assembly 1

28 61017401 Pressure Cylinder SR280RC8.4.11A 1

29 13129258 Auxiliary Winch Assembly 1

30 13075292 Turntable Assembly 1

31 13166075 Lower Mast 1

#14300387 Mast Assembly
#Sany Rotary Drilling Rig  #Sany Rotary Drilling Rig parts
#sanyparts #sany  #SR405RH10 rotary drilling rig body
#Rotary Rig #sanyparts #sany # #SR405RH10
WhatsApp: 136 8539 5801
WhatsApp: 136 8539 5801
WeChat: 136 8539 5801
3 13008751 M30 Rubber Plug 7

4 13122049 Shaft End Baffle 6

6 21001328 Washer 15

24 14285438 Upper Mast 1

25 13168941 Extended Mast Assembly 1

32 13156678 Mounting Base 2

33 A210111000203 Bolt 4

34 21001334 Washer 12GB97.1 300HV 16

35 13156636 Crossbeam 2

36 11900263 Guide Rail Positioning Pin 6

37 A210508000064 Pin Shaft 4

38 13156583 Connecting Rod 2

39 A210508000062 Pin B20×80 GB882 2

40 A210501000008 Pin 6

41 A210110000221 Bolt M24×130 GB5782 10.9 grade 13

42 10254681 Spacer 13

43 A210405000028 Washer 24 GB97.1 300HV 13

44 A210309000007 Nut M24 GB6172.1 13

45 A210307000007 Nut 13

46 13277129 Pin 2

47 A210111000197 Bolt M10×25 GB5783 10.9 12
